Extraction functions for objects of class 'arx'

Usage

# S3 method for class 'arx'
coef(object, spec=NULL, ...)
  # S3 method for class 'arx'
fitted(object, spec=NULL, ...)
  # S3 method for class 'arx'
logLik(object, ...)
  # S3 method for class 'arx'
model.matrix(object, spec=c("mean","variance"), response=FALSE, as.zoo=TRUE, ...)
  # S3 method for class 'arx'
plot(x, spec=NULL, col=c("red","blue"),
    lty=c("solid","solid"), lwd=c(1,1), ...)
  # S3 method for class 'arx'
print(x, signif.stars=TRUE, ...)
  # S3 method for class 'arx'
residuals(object, std=FALSE, ...)
  # S3 method for class 'arx'
sigma(object, ...)
  # S3 method for class 'arx'
summary(object, ...)
  # S3 method for class 'arx'
vcov(object, spec=NULL, ...)

Arguments

object

an object of class 'arx'

x

an object of class 'arx'

spec

NULL, "mean", "variance" or, in some instances, "both". When NULL is a valid value, then it is automatically determined whether information pertaining to the mean or variance specification should be returned

response

logical. If TRUE, then the response is included in the first column

as.zoo

logical. If TRUE (default), then the returned matrix is of class zoo

signif.stars

logical. If TRUE, then p-values are additionally encoded visually, see printCoefmat

std

logical. If FALSE (default), then the mean residuals are returned. If TRUE, then the standardised residuals are returned

col

colours of actual (default=blue) and fitted (default=red) lines

lty

types of actual (default=solid) and fitted (default=solid) lines

lwd

widths of actual (default=1) and fitted (default=1) lines

...

additional arguments

Value

coef:

a numeric vector containing parameter estimates

fitted:

a zoo object with fitted values

logLik:

log-likelihood (normal density)

model.matrix:

a matrix with the regressors and, optionally, the response

plot:

a plot of the fitted values and the residuals

print:

a print of the estimation results

residuals:

a zoo object with the residuals

sigma:

the regression standard error ('SE of regression')

summary:

a print of the items in the arx object

vcov:

variance-covariance matrix

See also

Examples

##simulate from an AR(1):
set.seed(123)
y <- arima.sim(list(ar=0.4), 40)

##simulate four independent Gaussian regressors:
xregs <- matrix(rnorm(4*40), 40, 4)

##estimate an 'arx' model: An AR(2) with intercept and four conditioning
##regressors in the mean, and log-ARCH(3) in the variance:
mymod <- arx(y, mc=TRUE, ar=1:2, mxreg=xregs, arch=1:3)

##print results:
print(mymod)
#>
#> Date: Sat Jul 27 15:29:47 2024
#> Dependent var.: y
#> Method: Ordinary Least Squares (OLS)
#> Variance-Covariance: Ordinary
#> No. of observations (mean eq.): 38
#> Sample: 3 to 40
#>
#> Mean equation:
#>
#>             coef std.error  t-stat p-value
#> mconst  0.012935  0.158622  0.0815 0.93553
#> ar1     0.433919  0.184652  2.3499 0.02532 *
#> ar2    -0.158899  0.179586 -0.8848 0.38307
#> mxreg1  0.212861  0.207773  1.0245 0.31353
#> mxreg2  0.177448  0.193842  0.9154 0.36704
#> mxreg3  0.213397  0.143935  1.4826 0.14828
#> mxreg4 -0.052338  0.181769 -0.2879 0.77531
#> ---
#> Signif. codes:  0 ‘***’ 0.001 ‘**’ 0.01 ‘*’ 0.05 ‘.’ 0.1 ‘ ’ 1
#>
#> Log-variance equation:
#>
#>             coef std.error  t-stat p-value
#> vconst -0.618004  0.802233  0.5934  0.4411
#> arch1  -0.101829  0.179553 -0.5671  0.5747
#> arch2  -0.097682  0.153166 -0.6378  0.5283
#> arch3  -0.026241  0.154150 -0.1702  0.8659
#>
#> Diagnostics and fit:
#>
#>                   Chi-sq df p-value
#> Ljung-Box AR(3)   5.2768  3  0.1526
#> Ljung-Box ARCH(4) 3.0297  4  0.5529
#>
#> SE of regression   0.97003
#> R-squared          0.25544
#> Log-lik.(n=35)   -46.34537

##plot the fitted vs. actual values, and the residuals:
plot(mymod)


##print the entries of object 'mymod':
summary(mymod)
#>                  Length Class      Mode
#> call              6     -none-     call
#> date              1     -none-     character
#> version           1     -none-     character
#> aux              20     -none-     list
#> n                 1     -none-     numeric
#> k                 1     -none-     numeric
#> df                1     -none-     numeric
#> coefficients      7     -none-     numeric
#> mean.fit         38     zoo        numeric
#> residuals        38     zoo        numeric
#> rss               1     -none-     numeric
#> sigma2            1     -none-     numeric
#> vcov.mean        49     -none-     numeric
#> logl              1     -none-     numeric
#> Elnz2             1     -none-     numeric
#> vcov.var          9     -none-     numeric
#> var.fit          38     zoo        numeric
#> std.residuals    38     zoo        numeric
#> ustar.residuals  38     zoo        numeric
#> variance.results  4     data.frame list
#> mean.results      4     data.frame list
#> diagnostics       6     -none-     numeric

##extract coefficient estimates (automatically determined):
coef(mymod)
#>      mconst         ar1         ar2      mxreg1      mxreg2      mxreg3
#>  0.01293470  0.43391913 -0.15889898  0.21286069  0.17744754  0.21339735
#>      mxreg4      vconst       arch1       arch2       arch3       Elnz2
#> -0.05233799 -0.61800361 -0.10182905 -0.09768241 -0.02624072 -1.51108503

##extract mean coefficients only:
coef(mymod, spec="mean")
#>      mconst         ar1         ar2      mxreg1      mxreg2      mxreg3
#>  0.01293470  0.43391913 -0.15889898  0.21286069  0.17744754  0.21339735
#>      mxreg4
#> -0.05233799

##extract log-variance coefficients only:
coef(mymod, spec="variance")
#>      vconst       arch1       arch2       arch3       Elnz2
#> -0.61800361 -0.10182905 -0.09768241 -0.02624072 -1.51108503

##extract all coefficient estimates:
coef(mymod, spec="both")
#>      mconst         ar1         ar2      mxreg1      mxreg2      mxreg3
#>  0.01293470  0.43391913 -0.15889898  0.21286069  0.17744754  0.21339735
#>      mxreg4      vconst       arch1       arch2       arch3       Elnz2
#> -0.05233799 -0.61800361 -0.10182905 -0.09768241 -0.02624072 -1.51108503

##extract regression standard error:
sigma(mymod)
#> [1] 0.9700325

##extract log-likelihood:
logLik(mymod)
#> 'log Lik.' -46.34537 (df=7)

##extract variance-covariance matrix of mean equation:
vcov(mymod)
#>               mconst           ar1           ar2       mxreg1       mxreg2
#> mconst  0.0251610272 -0.0015285628  0.0005370087 -0.002488587  0.002689960
#> ar1    -0.0015285628  0.0340965226 -0.0137456546  0.009800237 -0.009656845
#> ar2     0.0005370087 -0.0137456546  0.0322510692 -0.009227215 -0.001875021
#> mxreg1 -0.0024885867  0.0098002369 -0.0092272152  0.043169627  0.004287598
#> mxreg2  0.0026899595 -0.0096568451 -0.0018750214  0.004287598  0.037574668
#> mxreg3  0.0009279521  0.0003525202 -0.0060498526 -0.004381605  0.002430933
#> mxreg4  0.0008675077  0.0006219531  0.0033660813 -0.008426761 -0.001919049
#>               mxreg3        mxreg4
#> mconst  0.0009279521  0.0008675077
#> ar1     0.0003525202  0.0006219531
#> ar2    -0.0060498526  0.0033660813
#> mxreg1 -0.0043816051 -0.0084267606
#> mxreg2  0.0024309326 -0.0019190488
#> mxreg3  0.0207172909 -0.0035607424
#> mxreg4 -0.0035607424  0.0330397967

##extract variance-covariance matrix of log-variance equation:
vcov(mymod, spec="variance")
#>             arch1       arch2       arch3
#> arch1 0.032239225 0.002548225 0.003175857
#> arch2 0.002548225 0.023459962 0.002435217
#> arch3 0.003175857 0.002435217 0.023762073

##extract and plot the fitted mean values (automatically determined):
mfit <- fitted(mymod)
plot(mfit)


##extract and plot the fitted variance values:
vfit <- fitted(mymod, spec="variance")
plot(vfit)


##extract and plot both the fitted mean and variance values:
vfit <- fitted(mymod, spec="both")
plot(vfit)


##extract and plot the fitted mean values:
vfit <- fitted(mymod, spec="mean")
plot(vfit)


##extract and plot residuals:
epshat <- residuals(mymod)
plot(epshat)


##extract and plot standardised residuals:
zhat <- residuals(mymod, std=TRUE)
plot(zhat)
