Plot a Forecast Object of the OSEM Model

Usage

# S3 method for class 'osem.forecast'
plot(
  x,
  title = "OSEM Model Forecast",
  exclude.exogenous = TRUE,
  order.as.run = FALSE,
  interactive = FALSE,
  first_date = NULL,
  grepl_variables = NULL,
  return.data = FALSE,
  ...
)

Arguments

x: An object of class osem.forecast, which is the output from the forecast_model function.
title: Character. Title of the plot. Default is "OSEM Model Forecast".
exclude.exogenous: Logical. Should exogenous values be plotted? Default is FALSE.
order.as.run: Logical. Should the plots be arranged in the way that the model was run? Default FALSE.
interactive: Logical. Should the resulting plot be launched in an interactive way (the plotly package is required for this).
first_date: Character. First date value to be shown. Must be a character value that can be turned into a date using as.Date() or NULL.
grepl_variables: Regular Expression Character. Can be used to select variables to be plotted. Experimental feature so use with care.
return.data: Logical. Do not return a plot but rather just the final dataset that has been created for the plot.
...: Additional arguments passed to the plotting function.

Examples

spec <- dplyr::tibble(
type = c(
  "d",
  "d",
  "n"
),
dependent = c(
  "StatDiscrep",
  "TOTS",
  "Import"
),
independent = c(
  "TOTS - FinConsExpHH - FinConsExpGov - GCapitalForm - Export",
  "GValueAdd + Import",
  "FinConsExpHH + GCapitalForm"
)
)
# \donttest{
a <- run_model(specification = spec, dictionary = NULL,
inputdata_directory = NULL, primary_source = "download",
save_to_disk = NULL, present = FALSE)
#> Dataset query already saved in cache_list.json...
#> Reading cache file /tmp/RtmpepJCbG/eurostat/ec5b6dd50558d283aef43fac7d6aa37d.rds
#> Table  namq_10_a10  read from cache file:  /tmp/RtmpepJCbG/eurostat/ec5b6dd50558d283aef43fac7d6aa37d.rds
#> Dataset query already saved in cache_list.json...
#> Reading cache file /tmp/RtmpepJCbG/eurostat/76dc8973b5b70862c723fa812bda8980.rds
#> Table  namq_10_gdp  read from cache file:  /tmp/RtmpepJCbG/eurostat/76dc8973b5b70862c723fa812bda8980.rds
#>
#> --- Estimation begins ---
#> Estimating Import = FinConsExpHH + GCapitalForm
#> Constructing TOTS = GValueAdd + Import
#> Constructing StatDiscrep = TOTS - FinConsExpHH - FinConsExpGov - GCapitalForm - Export

plot(forecast_model(a))
#> No exogenous values provided. Model will forecast the exogenous values with an AR4 process (incl. Q dummies, IIS and SIS w 't.pval = 0.001').
#> Alternative is exog_fill_method = 'last'.



# }
